Spec - 23 individual printed circuit boards - More than 5500 discrete parts - Dual-differential musIC 3 128-bit-feed-forward error correction process - Fully balanced, dual mono design with complete physical and electrical separation of left and right channels - 10 purpose-wound, functionally specific power transformers - Digital circuitry time aligned to 100ps - 0.5uV of total rail noise (1Hz-100KHz): ultra sophisticated power supply with distributed regulation topology. - 30 local regulation stages, 5 stages of DC regulation. - User-adjustable gain and output impedance. - Zepto Reference clock: doubled the master clock frequency with only 12fs total jitter. Output Level: 1V / 2V / 4V Output impedance: 0 / 10 / 50 / 75 / 600 ohms Inputs: USB (32-384KHz, 16-24-32 bits, DSD64, DSD128, DSD256,MQA), 2xSPDIF RCA (32KHz-192KHz, 16-24 bits) 2xSPDIF BNC (32KHz-192KHz, 16-24 bits) 2xAES-EBU (32KHz-192KHz, 16-24 bits)Native Reference Wadax Link (native PCM, DSD), 3xAES-EBU, 1 RJ45 User interface: 5 inch capacitive touch full-colour display 800x480
